HELLA LED work light/light bar
Part no.: 4550016092
Further information
- Nominal voltage (V):
- 12 / 24
- Voltage range (V):
- 9 - 33
- Bulb:
- LED
- Bulbs included:
- Yes
- Light function:
- Far-reaching illumination
- Dimensions W x H x D (mm):
- 704 x 80 x 86
- Mounting type:
- Vertical/hanging
- Connection:
- DEUTSCH plug
- Material:
- Housing: aluminium, lens: plastic
- Protection class:
- IP67
- Width (mm):
- 704
- Form:
- Rectangular
- Height (mm):
- 86
- Current (A):
- 7,3 (12 V) / 3,6 (24 V)
- Depth (mm):
- 80
- Fixing:
- Hanging, vertical
- Type:
- Light bar LBX-720
- Housing material:
- Aluminium
- No. of LEDs:
- 12
- Cable length (mm):
- 2000
- Test mark:
- E 24, ECE-R10
- Power consumption (W):
- 88
- Number of pins:
- 2
- Type:
- LED
- Effective luminous flux (lm):
- 2200
- EMC:
- Radio interference suppression according to ECE R10
- Luminous flux (lm):
- 5500
- Light colour (K):
- 6500
- Operating temperature (°C):
- -40 / +60
- Light aperture (mm):
- 657 x 55
- Eligible:
- Environmental protection and safety (formerly de minimis)
- Weight:
- 4,00 kg
- EAN codes:
- 9002920161657
- Catalogue:
- Electrics (p. 755)
- To be found in category:
- ElectricsLightingWork lightsLED light bars
