BONDIOLI & PAVESI Gearbox

Further information

Transmission:

4,11:1

n1 (1/min.):

540

n2 (1/min.):

131

Power max. (PS/kW):

540 1/min.: 37 / 27

Torque (Nm):

540 rpm: n1 = 481, n2 = 1970

Description:

• Cast iron housing
• Bevel gear pairing spiral-toothed and case-hardened
• Speed limit: n = 540 rpm
• Weight: approx. 42 kg (without oil)
• Oil filling quantity: approx. 2.1 l
• Oil type: SAE90 EP
• Supplied without oil

Application:

• Auger up to approx. Ø 600 mm

Maintenance:

1st oil change after 50 operating hours, then at intervals of 500-800 hours, or once a year

Catalogue:

PTO shafts & drive technology (p. 490)
