Continental PVC hose
Meterware
Part no.: 4059130470320000
Further information
- Inner Ø (mm):
- 32
- Inner Ø (inches):
- 1 1/4"
- Outer Ø (mm):
- 42,5
- Working pressure (bar):
- 12
- Burst pressure (bar):
- 48
- Length (m):
- Meterware
- Bending radius (mm):
- 100
- Vacuum (bar):
- 0,9
- Wall thickness (mm):
- 5,25
- Temperature range (°C):
- -25 °C - +55 °C
- Hose type:
- Spiral hose
- Food safe:
- No
- Roll length (m):
- 60
- Wire Ø (mm):
- 1,2
- Weight (kg/m):
- 0,8
- Manufacturer:
- Wilhelm Fricke SE, Zum Kreuzkamp 7, 27404 Heeslingen, Deutschland, www.granit-parts.com, [email protected]
- Weight:
- 950 g
Application: Hose for conveying and drawing hydraulic oils and fuels, diesel, biodiesel and urea, and suitable for pesticides.
Properties: Made of thermoplastic PVC/PU/nitrile rubber compound with embedded steel wire spiral and polyester yarn inlay. Diameter 76/80/90/102/127, with copper wire in outer hose for antistatic conductivity.
Flexible, very strong, abrasion-resistant, smooth interior and exterior. Excellent tear resistance thanks to the polyurethane inlay in the outer sheath compound.
Temperature range: -25 °C to +55 °C
Sold by the metre
Properties: Made of thermoplastic PVC/PU/nitrile rubber compound with embedded steel wire spiral and polyester yarn inlay. Diameter 76/80/90/102/127, with copper wire in outer hose for antistatic conductivity.
Flexible, very strong, abrasion-resistant, smooth interior and exterior. Excellent tear resistance thanks to the polyurethane inlay in the outer sheath compound.
Temperature range: -25 °C to +55 °C
Sold by the metre
Cannot be returned.
