Comer Gearbox

Further information

Torque (Nm):

540 rpm: n1 = 274, n2 = 529

Application:

Reversing gearbox for front and rear operation
Agitator drives
General drives in agriculture, construction and forestry equipment
Axle spacing 79 mm

Version:

Cast iron housing
Gearing case hardened
Speed limit: 3000 rpm
Oil filling quantity: approx. 0.6 litres
Oil type: SAE90 EP
Supplied without oil
A torque arm should be considered as an anti-twist device

Power max. (PS/kW):

21 / 15,5

Transmission:

2:1

n1 (1/min.):

540

n2 (1/min.):

270

Maintenance:

1st oil change after 50 operating hours, then at intervals of 500-800 hours, or once a year

Weight:

17,61 kg
