Manuli Anaconda DN 25
MANULI hydraulic hose
Part no.: 11400414
Further information
- Nominal width:
- DN 25 - 1"
- Outer Ø (mm):
- 37.7
- Operating pressure max. (bar):
- 420
- Burst pressure (bar):
- 1680
- Bending radius (mm):
- 210
- Weight (g/m):
- 2012
- Press fitting (skive):
- 815M01500-16
- Press fitting (non-skive):
- 11396811
- Description:
- R15
- Version:
- 4 steel wire spiral inserts
- Type testing:
- MSHA; CU-TR
- Hose type:
- ANACONDA
- Weight:
- 2,10 kg
Advantages:
• Low bending force for difficult installations
• Bending radius exceeding standard requirements
• Good flexibility over the entire temperature range
• Easy assembly in static configurations
• High impulse strength according to ISO 18752
Interior: synthetic rubber
Inserts, reinforcement: four high-tensile steel spirals DN20 - DN32, six high-tensile steel spirals DN 38
Outer sheath: synthetic rubber with high abrasion, ozone, weather and heat resistance and an extended operating temperature range
Recommended fluids: mineral oil-based hydraulic fluids
Temperature range: -46°C to 121°C
Approvals: MSHA, CU-TR
• Low bending force for difficult installations
• Bending radius exceeding standard requirements
• Good flexibility over the entire temperature range
• Easy assembly in static configurations
• High impulse strength according to ISO 18752
Interior: synthetic rubber
Inserts, reinforcement: four high-tensile steel spirals DN20 - DN32, six high-tensile steel spirals DN 38
Outer sheath: synthetic rubber with high abrasion, ozone, weather and heat resistance and an extended operating temperature range
Recommended fluids: mineral oil-based hydraulic fluids
Temperature range: -46°C to 121°C
Approvals: MSHA, CU-TR
