Manuli GOLDENISO/35 XTRAFLEX DN 10
MANULI hydraulic hose
Part no.: 11377999
Further information
- Nominal width:
- DN 10 - 3/8"
- Outer Ø (mm):
- 18.9
- Operating pressure max. (bar):
- 350
- Burst pressure (bar):
- 1400
- Bending radius (mm):
- 80
- Weight (g/m):
- 530
- Press fitting (skive):
- 815M00910-06
- Press fitting (non-skive):
- 11387870
- Description:
- R13
- Version:
- 4 steel wire spiral inserts
- Type testing:
- DNV-GL; CU-TR; MSHA; FRAS; B; ABS; BV; LR; RINA;DNV-GL(MED); MA
- Hose type:
- GOLDENISO
Advantages:
• Bending radius that exceeds standard requirements
• Good flexibility over the entire temperature range
• Easy assembly in any configuration
• High pulse strength according to ISO 18752
• Weight saving of 20% compared with conventional R13 hose
Interior:
Synthetic rubber
Inserts, reinforcement:
DN10 - DN32: four high-tensile steel spirals
DN38, DN50: six high-tensile steel spirals
Outer cover:
Synthetic rubber with high abrasion, ozone, weather and heat resistance and an extended operating temperature range
Recommended fluids:
Mineral oil-based hydraulic fluids
Temperature range:
-46°C to 121°C
Approvals:
DNV-GL; CU-TR; MSHA; FRAS; B; ABS; BV; LR; RINA; DNV-GL(MED); MA
• Bending radius that exceeds standard requirements
• Good flexibility over the entire temperature range
• Easy assembly in any configuration
• High pulse strength according to ISO 18752
• Weight saving of 20% compared with conventional R13 hose
Interior:
Synthetic rubber
Inserts, reinforcement:
DN10 - DN32: four high-tensile steel spirals
DN38, DN50: six high-tensile steel spirals
Outer cover:
Synthetic rubber with high abrasion, ozone, weather and heat resistance and an extended operating temperature range
Recommended fluids:
Mineral oil-based hydraulic fluids
Temperature range:
-46°C to 121°C
Approvals:
DNV-GL; CU-TR; MSHA; FRAS; B; ABS; BV; LR; RINA; DNV-GL(MED); MA
